Description

H&R 40555712 TRAK+ DRA Wheel Spacers give compatible Audi A3, S3, A4 and S4 models a wider, more purposeful stance while retaining precise hub-centric location.

This silver anodised bolt-on axle kit adds 20 mm per wheel, producing 40 mm total track widening per axle. Each DRA spacer is first secured to the vehicle hub using the supplied fastening bolts, then the wheel is fitted to the spacer using the wheel’s existing bolts.

Key features

• 20 mm spacer thickness per wheel
• 40 mm total track widening per axle
• H&R TRAK+ DRA bolt-on system
• 5×112 bolt pattern
• 57.1 mm centre bore
• M14x1.5 wheel-bolt specification
• Silver anodised high-strength aluminium construction
• Hub-fastening hardware included
• Made in Germany

Verified vehicle families: Audi A3 and S3 8P/8V, plus Audi A4 and S4 B5/B6/B7, within the production years shown in Vehicle Fitment. S3 body styles are separated where the store already distinguishes Sportback, Sedan and Cabriolet models. Shared-SKU applications outside the two supplied A3/S3 and A4/S4 rows are deliberately excluded.

Ordering note: the length of each existing wheel bolt protruding through the wheel must be shorter than the 20 mm spacer thickness, exactly as H&R specifies for the DRA system. Confirm wheel-bolt seat type, wheel pockets, tyre size, offset, hub clearance and body clearance against the applicable H&R approval before ordering. Professional installation and a torque re-check after approximately 100 km are recommended.

SKU: 40555712

*Official representative H&R DRA spacer image. The pictured item is a 25 mm family example; this listing is the verified 20 mm-per-wheel application and exact machining details may vary.
